de alcance - 1.3-2.0 ton
Somos la primera empresa en Paraguay en contar con la mayor variedad de montacargas en el mercado. Desde montacargas para depósitos hasta equipos portuarios de alta performance; Engine está preparado para satisfacer todas las necesidades de trabajo.
| formance | 1 | Model | FBR13-M1JZ | FBR15-M1JZ | FBR20-M1JZ | FBR15-M3JZE | FBR20-M3JZE | |
| 2 | Power | Battery | ||||||
| 3 | Operation | Stand-on | Sitted-on | |||||
| 4 | Rated load capacity | Q(kg) | 1300 | 1500 | 2000 | 1500 | 2000 | |
| 5 | Rated lift height | h3(mm) | 3000 | |||||
| 6 | Load centre | C(mm) | 500 | |||||
| 7 | Fork carriage tilt (Forward/Backward) | α/β(deg) | 3°/5° | |||||
| 8 | Travel speed (Laden/Unladed) | (km/h) | 8.0/8.5 | 8.8/9.0 | 8.8/9.0 | 8.8/9.0 | 8.8/9.0 | |
| 9 | Lifting speed(Laden) | (mm/s) | 175 | 240 | 220 | 260 | 280 | |
| 10 | Max. gradeability (Laden) | (%) | 10 | |||||
| 11 | Min. turning radius | Wa(mm) | 1620 | 1725 | 1775 | 1690 | 1775 | |
| 12 | Reach distance | X(mm) | 700 | 600 | 645 | 550 | 650 | |
| 13 | Wheelbase | Y(mm) | 1360 | 1470 | 1520 | 1425 | 1500 | |
| 14 | Service brake | Mech | electromagnetic | electromagnetic | Hyd | |||
| Dimension and weight | 15 | Overall width | l1(mm) | 2125 | 2340 | 2350 | 2385 | 2400 |
| 16 | Main body length | l2(mm) | 1055 | 1270 | 1280 | 1315 | 1330 | |
| 17 | Overall width | b1(mm) | 1045 | 1205 | 1216 | 1255 | 1266 | |
| 18 | Height of mast, lowered | h1(mm) | 2080 | 2090 | 2080 | |||
| 19 | Free lift height | h2(mm) | 330 | |||||
| 20 | Height of mast, extended | h4(mm) | 3960 | 4025 | ||||
| 21 | Height of overhead guard | h5(mm) | 2210 | 2260 | 2100 | |||
| 22 | Fork dimensions (T×W×L) | (mm) | 35×100 ×920 | 35×122 ×920 | 40×122 ×920 | 35×122 ×920 | 40×122 ×920 | |
| 23 | Fork regulating range (Min/Max) | (mm) | 260/700 | 286/758 | 286/758 | |||
| 24 | Min. ground clearance | h6(mm) | 80 | |||||
| 25 | Aisle width with pallet (1200×1200) | Ast1(mm) | 2710 | 2910 | 2920 | 2945 | 2960 | |
| 26 | Aisle width with pallet (1000×1000) | Ast2(mm) | 2495 | 2690 | 2700 | 2725 | 2750 | |
| 27 | Service weight | (kg) | 2150 | 2670 | 2725 | 2850 | 3000 | |
| Driven | 28 | Drive motor | (Kw) | 2.5 | 4.5 | 4.5 | 4.5 | 4.5 |
| 29 | Lift motor | (Kw) | 3.5 | 11 | 11 | 11 | 11 | |
| 30 | Battery:Voltage /capacity (5h)standard (option) | (V/Ah) | 48/210 | 48/420 | 48/480 | |||
| Tyres | 31 | Tyres | Polyurethane Solid tyre | |||||
| 32 | Size of front tyre | (mm) | ￠250×70 | ￠250×120 | ￠285×108 | ￠343×108 | ||
| 33 | Size of driven tyre | (mm) | ￠381×130 | ￠381×130 | ￠343×132 | |||
| 34 | Size of balancing tyre | (mm) | ￠178×75 | ￠178×75 | – | |||
| 35 | Track width(front) | (mm) | 975 | 1070 | 1110 | 1125 | ||
| 36 | Track width(rear) | (mm) | 490 | 580 | – | |||
| Other | 37 | Turning system | Hyd | |||||
| 38 | Speed control system | ZAPI | ZAPI | ZAPI | ZAPI | ZAPI | ||
