SERIE a - 1.5-3.5 TON - 4 Ruedas
Somos la primera empresa en Paraguay en contar con la mayor variedad de montacargas en el mercado. Desde montacargas para depósitos hasta equipos portuarios de alta performance; Engine está preparado para satisfacer todas las necesidades de trabajo.
|
Specification |
1 |
Model |
FB15-AJZ |
FB18-AJZ |
FB20-AJZ |
FB25-AJZ |
FB30-AJZ |
FB35-AJZ |
||
|
2 |
Rated capacity |
kg |
1500 |
1800 |
2000 |
2500 |
3000 |
3500 |
||
|
3 |
Load centre |
mm |
500 |
|||||||
|
4 |
Lifting height |
mm |
3000 |
|||||||
|
5 |
Free lifting height |
mm |
135 |
140 |
165 |
|||||
|
6 |
Fork size |
T×W×L |
mm |
35×100×920 |
40×122×1070 |
45×125×1070 |
50×130×1070 |
|||
|
7 |
Tilting angle |
F/R（α°/β°） |
Deg |
5/10 |
||||||
|
Dimensions |
8 |
Overall Dimension |
Length (to forkface） |
mm |
2073 |
2118 |
2286.5 |
2548 |
2639 |
|
|
9 |
Width |
mm |
1120 |
1285 |
1285 |
1365 |
||||
|
10 |
Height when mast
lowered |
mm |
2000 |
2015 |
2045 |
2120 |
||||
|
11 |
Height when mast
extended
|
mm |
3980 |
3990 |
4100 |
4140 |
||||
|
12 |
Height to safeguard |
mm |
2135 |
2152 |
2152 |
2138 |
||||
|
13 |
Turning radius |
Min. |
mm |
1965 |
2080 |
2349 |
2405 |
|||
|
14 |
Front overhang |
mm |
410 |
454 |
475 |
495.5 |
||||
|
15/16 |
Tread |
F/R |
mm |
955/920 |
1058/960 |
1065/980 |
1124/1010 |
|||
|
17 |
Ground clearance |
Min. |
mm |
105 |
95 |
110 |
83 |
|||
|
18 |
Wheelbase |
mm |
1380 |
1485 |
1670 |
1690 |
||||
|
19 |
Fork spread |
Min./Max. |
mm |
250/890 |
250/1000 |
250/1060 |
||||
|
20 |
Working aisle width
with pallet(Ast)*
|
1000×1200 crossways |
mm |
3541 |
3732 |
4025 |
4101 |
|||
|
21 |
800×1200
lengthways |
mm |
3741 |
3932 |
4225 |
4301 |
||||
|
Performance |
22 |
Speed |
Travel(Laden) |
km/h |
15 |
15 |
15 |
|||
|
23 |
Travel(Unladen) |
km/h |
16 |
16 |
16 |
|||||
|
24 |
Lifting(Laden) |
mm/s |
290 |
280 |
280 |
|||||
|
25 |
Lifting(Unladen) |
mm/s |
440 |
440 |
400 |
384 |
||||
|
26 |
Gradeability |
Laden |
% |
15 |
15 |
15 |
||||
|
27 |
Unladed |
% |
15 |
15 |
15 |
|||||
|
28 |
Service weight |
Include battery box |
kg |
2950 |
3230 |
3930 |
4100 |
4750 |
5253 |
|
|
29 |
Tyre |
Front×2 |
6.00-9 10PR |
23×9-10 16PR |
23×9-10 16PR |
23×10-12 |
||||
|
30 |
Rear×2 |
5.00-8 8PR |
18×7-8-14PR |
18×7-8-14PR |
200/50-10 |
|||||
|
Driven |
31 |
Motor |
Driven motor |
kw |
K6.5 |
K8.5 |
K11.5 |
|||
|
32 |
Pump motor |
kw |
K8.6 |
K11 |
K15 |
|||||
|
33 |
Battery |
Standard(Option) |
V/Ah |
48/420 |
48/600 |
80/500 |
||||
|
34 |
Controller |
Type |
AC |
AC |
AC |
AC |
AC |
AC |
||
|
35 |
Manufacturer |
ZAPI |
ZAPI |
ZAPI |
ZAPI |
ZAPI |
ZAPI |
|||
|
36 |
Operating pressure
for attachment |
Mpa |
14.5 |
17.5 |
||||||
